Electronics Tutorial Video
Learning to use a new oscilloscope can be daunting!
In this video, I show five measurements you can make using just an Arduino as your DUT. Learn how to offset voltage, set up measurements, enable infinite persistence, save reference waveforms, AND trigger (and decode) serial signals.
For this video, Rohde & Schwarz was kind enough to send me an RTM3004.
Check out the links below for more.
Episode #28 Show Notes and Links
Rohde & Schwarz RTM3004 Oscilloscope
Official Arduino Uno
6 Measurements to learn a scope on baldengineer.com
